SPECIFICATIONS
- additional pan handle: 504HLV
- attachment: 3/8'' male thread attachment type
- attachment number: 1/4'' and 3/8'' screws attachment type
- balance control: 4 step: 0Kg – 2.5Kg – 5Kg – 7.5Kg
- front tilt: -60° / +90° tilt range
- half ball diameter: 75.0 mm
- independent pan lock: yes
- independent tilt lock: yes
- levelling bubble: illuminated
- maximum working temperature: 60
- minimum working temperature: -20
- pan bar positions: 2 number
- pan bars included (no.): 1 number
- pan drag: continuously adjustable from 0 to max level
- panoramic rotation: 360 °
- plate type: 504PLONG
- quick release: yes
- secondary safety system: yes
- sliding travel of plate: 83.0 mm
- tilt drag: continuously adjustable from 0 to max level
- load capacity: 7.5 kg
- weight: 2.9 kg
- working height: 15.5 cm
