SPECIFICATIONS
- additional pan handle: 509HLV
- attachment: 3/8" male thread attachment type
- attachment number: 1/4" and 3/8" screws attachment type
- balance control: 4 step: 0kg – 4.3kg – 8.65kg – 13kg
- front tilt: -60° / +90° tilt range
- half ball diameter: 100.0 mm
- independent pan lock: yes
- independent tilt lock: yes
- levelling bubble: illuminated
- material: aluminum
- maximum working temperature: 60
- minimum working temperature: -20
- pan bar positions: 2 number
- pan bars included (no.): 1 number
- pan drag: continuously adjustable from 0 to max level
- panoramic rotation: 360 °
- patent: pat. pending
- plate type: 509PLONG
- quick release: yes
- secondary safety system: yes
- sliding travel of plate: 83.0 mm
- tilt drag: continuously adjustable from 0 to max level
- load capacity: 13 kg
- weight: 3.8 kg
- working height: 17.8 cm
